Rexroth 4WRZ 16 W6-150-7X/6EG24N9ETK4/M (R900618110)Proportional Directional Valve

Description

Rexroth 4WRZ 16 W6-150-7X/6EG24N9ETK4/M (R900618110)Proportional Directional Valve – Product Description and Introduction

Product Overview:
This product is a Bosch Rexroth 4WRZ series 2-way 4-port and 3-way 4-port proportional directional valve. It features a pilot-operated design without integrated electronic position feedback. The valve has a port size of 16 mm and can achieve a maximum flow rate of 150 L/min with a pressure drop of 10 bar.

Key Features:
1. Model number: 4WRZ 16 W6-150-7X/6EG24N9ETK4/M(R900618110)
2. Valve type: 2-way 4-port and 3-way 4-port proportional directional valve
3. Design: Pilot-operated, without electronic position feedback
4. Port size: 16 mm
5. Maximum flow rate: 150 L/min
6. Rated pressure drop: 10 bar
7. Series: 70-79 series
8. Mounting: Sandwich mounting
9. Pilot control: Proportional solenoid, detachable coil, 24V DC supply
10. Manual emergency operation: Equipped with concealed manual override
11. Control oil circuit: Internal oil supply, internal oil return
12. Electrical interface: Plug-in connector, without mating cable socket
13. Sealing material: NBR, suitable for mineral oils

This product is widely used in industrial automation, machinery equipment, and mobile applications, offering high flow capacity, stable performance, and precise control. When using this valve, please follow the relevant safety operating procedures and select the appropriate hydraulic fluid.
