Rexroth 3DREE10P-7X/315YG24K31F1V R901226056 Pressure Reducing Valve

Description

Rexroth 3DREE10P-7X/315YG24K31F1V R901226056 Pressure Reducing Valve – Product Introduction and Specifications

1. Product Overview:
The 3DREE10P-7X/315YG24K31F1V is a pilot-operated, three-way pressure reducing valve manufactured by Bosch Rexroth. It features a proportional solenoid control, centralized threaded ports, and a removable coil design, making it suitable for manifold mounting. This pressure reducing valve is designed for use in hydraulic systems, providing precise pressure control and limitation.

2. Key Features:
– Pilot-operated design effectively reduces system pressure and improves system stability
– Proportional solenoid control enables continuous pressure adjustment
– Centralized threaded ports and removable coil design facilitate easy installation and maintenance
– Conforms to DIN 24340-A and ISO 4401 standards for mounting surface
– Linear control value/pressure characteristic curve ensures excellent control performance
– Integrated OBE electronic components enhance system intelligence

3. Working Principle:
The pressure reducing valve consists of a pilot valve, a proportional solenoid, and a main valve. The proportional solenoid adjusts the control chamber pressure, which in turn moves the main spool to continuously regulate the pressure at port A. When the pressure at port A exceeds the set value, the main spool will further shift to the left, limiting the pressure to the set point, providing pressure protection.

4. Applications:
This pressure reducing valve is widely used in various hydraulic systems, where pressure control and limitation are required, contributing to improved system stability and safety. Typical applications include, but are not limited to, construction machinery, machine tools, and metallurgical equipment.

5. Model Explanation:
3DREE10P-7X/315YG24K31F1V
– 3DREE: Pilot-operated, three-way pressure reducing valve，without maximum pressure limitation.
– 10: Valve body size
– P: Subplate mounting
– 7X:Component series 70 … 79 (70 … 79: unchanged installation and mounting dimensions）
– 315: Maximum pressure 315(bar)
– Y: With electronic components
– G24: 24V DC power supply
– K31: Electronic component model
– F1: Cable connection type
– V: FKM SEAL

In summary, the Bosch Rexroth 3DREE10P-7X/315YG24K31F1V pressure reducing valve is a high-performance, versatile hydraulic component that can be widely applied in various hydraulic systems.
