Parker Super Coil CCS012D

Description

**Parker CCS012D Coil Specification and Introduction**

**Product Description**

The Parker CCS012D coil is a 1/2″ Super Coil product, specifically designed for controlling and activating hydraulic systems. This coil is renowned for its low power consumption and high efficiency, making it an ideal choice for applications requiring low voltage and continuous operation.

**Technical Features**

* Low power consumption design: 14 W, suitable for low voltage applications
* 12 VDC voltage: compatible with most hydraulic systems’ power requirements
* Din connection type: standard connection port, easy to install and maintain
* No diode: ensures the coil’s high reliability and low power consumption
* High flow rate: 1.15 A continuous flow rate, ensuring the coil’s high efficiency
* Low resistance: 10.43 Ω, ensuring the coil’s low power consumption and high efficiency
* Continuous operation: can operate continuously at 100% voltage for 24 hours
* Standard coil type: compatible with most hydraulic systems
* 1/2″ Super Coil: suitable for controlling and activating most hydraulic systems
* High temperature resistance: maximum operating temperature 392 °F (200 °C), suitable for high-temperature environments
* Low temperature resistance: minimum operating temperature -40 °F (-40 °C), suitable for low-temperature environments
* Lightweight design: only 0.2 lb (0.44 kg), easy to install and transport

**Applications**

* Hydraulic systems
* Control valves
* Actuation devices
* Low voltage applications
* Continuous operation applications

**Note**

* 1/2″ coils are typically used with 08 and 09 size cards or with the main control valve. Low power coils are usually used for low-pressure applications (less than 3000 PSI), while high-power coils are used for high-pressure applications (up to 5000 PSI).
* For additional voltage or terminal options, please consult the factory.
