Parker RDM2PT35SVG Hydraulic Valve
Parker RDM2PT35SVG Hydraulic Valve
Parker RDM2PT35SVG Hydraulic Valve – Series RDM Product Specifications and Description
Product Specifications:
- Adjustment Mechanism: Hexagon socket
- Seal Material: FPM
- Mounting Type: Sandwich plate
- Operation Type: Direct
- Actuation Type: Manual
- Gauge Port: G1/4
- Product Series: Pressure valve
- Weight: 1.3 kg
- Maximum Flow Rate: 40 L/min
- Maximum Operating Pressure: 350/50 bar
- Maximum Operating Temperature: 60 °C
- Minimum Operating Temperature: -20 °C
- Body Material: Steel
- For Fluid Type: Hydraulic oil
- Pressure Relief Valve: P to T
- Pressure Control Range: 5 to 350 bar
- Port Connection: NG06
- Gauge Port Size: G 1/4
- Adjustment Mechanism: Hexagon socket
- Pressure Relief Valve Type: Direct operated
- Function: Pressure relieved from P to T
- Pressure Range (bar): 5-350
- Nominal Size: NG06 / CETOP 03
Product Description: Parker’s RDM2PT35SVG hydraulic valve is part of the RDM series and features a sandwich plate design, enabling easy configuration of stack systems. These direct operated piston type valves provide precise pressure control with low hysteresis. The RDM series can be used as a P-T relief valve or as a T-T controlled counter balance valve. The valve body is equipped with a pressure gauge port.
Please note: The product specifications and description provided are based on the given information and are subject to change without prior notice.
