Parker PVL-C123619 Pneumatic Valve

Description

Parker PVL-C123619 Pneumatic Valve

Product Description for Parker PVL-C123619 Pneumatic Valve Module

Product Name: Parker PVL-C123619 Pneumatic Valve Module

Model: PVL-C123619

Compatible Valve Body: Parker PVL-C series 1/4 inch valve body

Main Features:

– Designed as a 5/2 single acting spring return valve module

– Interface adopts G1/4 inch threaded port

– Weight of 240g

– Suitable for compressed air or inert gas filtered to 40 microns

– Working pressure of 2-10 bar, nominal flow rate of 1100mL/min

– Working temperature of -15°C to +60°C, storage temperature of -40°C to +70°C

– Response time of 26/60ms, maximum operating frequency of 5Hz

– Standard voltage of 24V DC

– Protection level of IP65, can work in any direction

Application Scope:

– As a 5/2 single acting spring return valve module for PVL-C series valve body

– Adopts reliable G1/4 inch threaded port

– Suitable for applications requiring medium flow rate and internal spring return function

– Can be stacked into a modular valve system

– Suitable for pneumatic control systems requiring internal spring return function

– Can be integrated into PVL-C series valve body modules

This valve module is suitable for applications requiring 5/2 single acting spring return function, adopting G1/4 inch threaded port.
