Parker PVL-C123613 Pneumatic Valve
Product Description for Parker PVL-C123613 Pneumatic Valve Module
Product Name: Parker PVL-C123613 Pneumatic Valve Module
Model: PVL-C123613
Compatible Valve Body: Parker PVL-C series 1/4 inch valve body
Main Features:
– Designed as a 5/2 single acting spring return valve module
– Interface adopts G3/8 inch threaded port
– Weight of 240g
– Suitable for compressed air or inert gas filtered to 40 microns
– Working pressure of 2-10 bar, nominal flow rate of 1100mL/min
– Working temperature of -15°C to +60°C, storage temperature of -40°C to +70°C
– Response time of 26/60ms, maximum operating frequency of 5Hz
– Standard voltage of 24V DC
– Protection level of IP65, can work in any direction
Application Scope:
– As a 5/2 single acting spring return valve module for PVL-C series valve body
– Adopts reliable G3/8 inch threaded port
– Suitable for applications requiring medium flow rate and internal spring return function
– Can be stacked into a modular valve system
– Suitable for pneumatic control systems requiring internal spring return function
– Can be integrated into PVL-C series valve body modules
This valve module is suitable for applications requiring 5/2 single acting spring return function, adopting G3/8 inch threaded port.
