Parker PVL-C122419 Pneumatic Valve

Description

Parker PVL-C122419 Pneumatic Valve

Product Information for Parker PVL-C122419 Pneumatic Valve Module

Product Name: Parker PVL-C122419 Pneumatic Valve Module

Model: PVL-C122419

Compatible Valve Series: Parker PVL-C Series Valve Bodies

Key Features:

– Designed as a 5/2 double acting valve module for PVL-C series stackable valve bodies.

– Interface is G1/4″ threaded port.

– Weight of 230g.

– Suitable for compressed air or inert gases filtered to 40 microns.

– Working pressure of 2-10 bar, nominal flow rate of 1100 ml/min.

– Working temperature range of -15°C to +60°C, storage temperature of -40°C to +70°C.

– Maximum operating frequency of 10Hz.

– Standard voltages of 12VDC, 24VDC, 48VDC.

– Protection class of IP65, can operate in any orientation.

Application:

– To be used as a 5/2 double acting valve module in PVL-C series.

– With G1/4″ threaded interface.

– Can be stacked together with other PVL-C modules to form a valve island assembly.

– Suitable for applications requiring a 5/2 double acting function.

– Can be integrated into PVL-C series valve body modules.

This valve module is suitable for applications requiring a 5/2 double acting function with a G1/4″ threaded interface.
