Parker PVL-C121408 Pneumatic Valve

Description

Parker PVL-C121408 Pneumatic Valve

Parker PVL-C121408 Pneumatic Valve Module Product Description

Product Name: Parker PVL-C121408 Pneumatic Valve Module

Model: PVL-C121408

Applicable Valve Body: Parker PVL-C Series Valve Body

Main Features:

– Designed as a 5/2 single acting valve module for the PVL-C stacking series.

– Interface uses G1/4″ threaded port or Ø8mm push-in fitting connection.

– Weight of 250g

– Suitable for compressed air or inert gas filtered to 40 microns

– Working pressure of 2-10 bar, nominal flow rate of 1100ml/min

– Working temperature range of -15°C to +60°C, storage temperature of -40°C to +70°C

– Maximum operating frequency of 5Hz

– Standard voltages of 12VDC, 24VDC, 48VDC

– Protection rating of IP65, can operate in any orientation

Application:

– As a PVL-C series 5/2 single acting valve module

– Uses a G1/4″ threaded port or Ø8mm push-in fitting interface

– Can be stacked together with other PVL-C modules

– Suitable for applications requiring 5/2 single acting function

– Can be integrated into PVL-C series valve body modules

This valve module is suitable for applications requiring a 5/2 single acting function using a G1/4″ threaded port or Ø8mm push-in fitting connection and stacking with other PVL-C modules.
