Parker PVL-B113606 Pneumatic Valve

Description

Parker PVL-B113606 Pneumatic Valve

Product Information – Parker PVL-B113606 Pneumatic Valve Module

Product Name: Parker PVL-B113606 Pneumatic Valve Module

Model: PVL-B113606

Applicable Series: Parker PVL-B Standalone Valve Series

Main Features:

– Designed as a 5/2 single acting internal exhaust valve module for the PVL-B standalone valve series.

– Interface adopts Ø6mm push-in fitting.

– Weight of 125g.

– Suitable for compressed air or inert gas filtered to 40 microns.

– Working pressure of 3-10 bar, nominal flow rate of 540 ml/min.

– Working temperature of -15°C to +60°C, storage temperature of -40°C to +70°C.

– Maximum operating frequency of 5Hz.

– Standard voltages of 12VDC, 24VDC, 48VDC.

– Protection level of IP65, can work in any direction.

Application:

– As a 5/2 single acting internal exhaust valve module for the PVL-B series.

– Using Ø6mm push-in fitting interface.

– Applicable where 5/2 single acting internal exhaust function is needed.

– Can be used independently as a standalone valve.

This valve module is suitable for applications requiring 5/2 single acting internal exhaust function and using Ø6mm push-in fitting interface.
