Parker IPD12222110 Inline Particle Monitor – iCountPD
**Product Introduction**
The Parker iCountPD is a highly compact, permanently installed laser-based particle size monitoring system that continuously monitors contamination levels in hydraulic and fluid circuits. This device represents the latest technology in real-time particle contamination analysis, providing a cost-effective solution for fluid management and condition monitoring in applications ranging from construction machinery to industrial plant equipment and test rigs.
**Technical Specifications**
* Interface Type: Deutsch DT Series
* Brand: Parker
* Signal Output: 4-20 mA
* Department: Hydraulic and Industrial Process Filters EMEA
* Indicator Type: LED
* Industry: Industrial and Chemical Processing, Industrial Manufacturing Equipment, General Industrial
* ATEX Certification: Not Applicable
* Housing Material: ABS
* Fluid Type: Mineral Oil
* Options: None
* Product Type: Condition Monitoring Instrument
* Technology: Filtration, Hydraulic
* Limit Value Alarm Relay: Yes
* Product Style: Particle Detector/Counter
* Operating Pressure: 30-6000 psi, 2-420 bar
* Flow Rate: 60 L/min
* Interface Size: M16 x 2 hydraulic test point
* Interface Type: Metric
* Operating Temperature: 5-60°C, 41-140°F
* Maximum Fluid Temperature: 80°C
* Minimum Fluid Temperature: 5°C
* Operating Humidity: 5-100% (RH)
* Detection Method: Laser
* Accuracy: ±1 ISO code
* Electrical Requirements: 9-40 VDC
* Communication Interface: RS232
* Signal Output: 4-20 mA
* Cycle Time: 30 seconds
* Compliance: CE Certified
* Ingress Protection: IP66
* Materials of Construction: ABS, Housing: ABS
* Seal Material: Fluorocarbon
* Main Body Material: Brass
* Fluid Type: Mineral oil and petroleum-based liquids
* Weight: 1.3 kg
* Height: 155 mm
* Length: 182 mm
* Width: 85 mm
**Application Scenarios**
The cleanliness level of hydraulic fluid is crucial for the performance and reliability of industrial equipment. Contamination levels high in liquid or solid particles can damage system components, such as pumps, actuators, or servo valves, leading to shortened maintenance intervals, increased downtime, and higher costs.
The iCountPD is available in three configurations to meet the unique requirements of customers’ applications. Options include:
* Standard iCountPD – Suitable for test stand, flushing skids, filter carts, and other industrial applications.
