Parker F2400S Flow Control Valve

Description

Parker F2400S Flow Control Valve

Model: F2400S

Overview

The F2400S is a 1.5-inch flow control valve from Parker’s F-series valve product line. It features a steel body construction.

Specifications

– Valve Body Size: 1.5 inch (Model 2400)

– Body Material: Steel (Material Code S)

– Port Connection: SAE-24 threaded ports

– Maximum Working Pressure: 5000 psi for steel body

Key Features

– Compact 1.5-inch steel body

– Soft seated ball design for precise flow control

– Color scale band for simple and visible flow setting

– Set screw to lock in flow setting

Performance

– Effective Orifice Area: Data unavailable

– Maximum Flow Coefficient: Data unavailable

Application

Suitable for hydraulic systems requiring steel construction and medium to high flow control accuracy.

Installation and Operation

– Ensure correct flow direction

– Adjust flow by turning the knob

– Tighten set screw to lock in flow setting

– Do not exceed 5000 psi working pressure

The Parker F2400S flow control valve features a steel construction, soft seated ball design to provide medium to high flow control capabilities for hydraulic systems. The color scale band and locking set screw make flow setting simple and efficient.
