Parker F200S Flow Control Valve

Description

Parker F200S Flow Control Valve

Parker F200S 1/2 inch Steel Body Flow Control Valve

Overview

The Parker F200S is a 1/2 inch flow control valve from Parker’s F-series. It features a steel body (S code) and 1/4 NPT threaded ports.

Specifications

– Body Size: 1/2 inch
– Body Material: Steel (S code)
– Port Connection: 1/4 NPT threaded ports
– Maximum Working Pressure: 350 bar (5000 psi)

Key Features

– 1/2 inch steel body construction
– Standard 1/4 NPT threaded ports
– Soft seat design for precise flow adjustment
– Color coded knob for simple flow setting
– Locking screw to fix the flow setting

Performance

– Effective Flow Area: Approx. 0.0044 square inches
– Maximum Cv: Approx. 0.0758

Application

Suitable for 1/2 inch flow control applications requiring high pressure resistance.

Installation and Operation

– Ensure correct flow direction
– Turn knob to adjust flow rate
– Tighten locking screw to fix the setting
– Do not exceed 350 bar (5000 psi) working pressure

The F200S utilizes a steel spring and spring seat design. The steel body provides high pressure resistance suitable for corrosive and high pressure applications.
