Parker F200B Flow Control Valve

Description

Parker F200B Flow Control Valve

Parker F200B 1/2 inch Brass Body Flow Control Valve

Overview

Parker F200B is a 1/2 inch flow control valve from Parker’s F series. It features a brass body (B code) and 1/4 NPT threaded ports.

Specifications

– Body Size: 1/2 inch
– Body Material: Brass (B code)
– Port Connection: 1/4 NPT threaded ports
– Maximum Working Pressure: 140 bar (2000 psi)

Key Features

– 1/2 inch brass body construction
– Standard 1/4 NPT threaded ports
– Soft seat design for precise flow adjustment
– Color coded knob for simple flow setting
– Locking screw to fix the flow setting

Performance

– Effective Flow Area: Approx. 0.0044 square inches
– Maximum Cv: Approx. 0.0758

Application

Suitable for 1/2 inch low pressure flow control applications requiring corrosion resistance.

Installation and Operation

– Ensure correct flow direction
– Turn knob to adjust flow rate
– Tighten locking screw to fix the setting
– Do not exceed 140 bar (2000 psi) working pressure

The F200B utilizes a spring and spring seat design. The brass body provides corrosion resistance suitable for low pressure corrosive applications.
