Parker D31FBE01EC4NF00 Proportional Directional Control Valve

Description

Parker D31FBE01EC4NF00 Proportional Directional Control Valve

The D31FBE01EC4NF00 is a proportional directional control valve from Parker’s D*1FB series, designed for precise flow control in hydraulic systems.

The ordering code for the D31FBE01EC4NF00 valve is as follows:

Ordering Code: D31FBE01EC4NF00
D31FBE – Valve Series and Size
01 – Valve Function and Flow
EC – Valve Options and Connections
4N – Solenoid Voltage and Seal Material
F00 – Valve Design and Special Options

The D31FBE01EC4NF00 valve has the following key technical parameters:

– Valve Type: Proportional Directional Control Valve
– Actuation: Proportional Solenoid
– Size: NG10 (CETOP 05)
– Mounting Interface: DIN 24340 / ISO 4401 / CETOP RP121 / NFPA
– Operating Pressure Range: Up to 350 bar
– Fluid: Hydraulic oil according to DIN 51524 … 535, other on request
– Temperature Range: -20°C to +60°C
– Nominal Flow: Please refer to the specific flow characteristics in the catalog
– Leakage at 100 bar: Please refer to the specific leakage rate in the catalog
– Solenoid Voltage: 24V
– Seal Material: NBR
– Electrical Characteristics: Please refer to the specific electrical characteristics in the catalog
– Dimensions: Standard dimensions, please refer to the specific dimensions in the catalog

The D31FBE01EC4NF00 valve is suitable for various hydraulic applications that require precise flow control. It features progressive flow characteristics and meets Parker’s high-quality standards.

For more information about the D31FBE01EC4NF00 valve and other proportional valves from Parker, please visit their official website or refer to the relevant catalog.
