Parker D31FBE01EC1NF00 Proportional Valve
Description
Parker D31FBE01EC1NF00 Proportional Valve
Parameter Specification:
– Model: D31FBE01EC1NF00
– Port Connection: NG10 / CETOP 05
– Operation Type: Pilot operated
– Actuation Type: Proportional solenoid
– Flow Rate: 120 L/Min
– Function: 3-way
– Maximum Flow Rate: N/A
– Spool Position: Operated in position a or b
– Maximum Operating Pressure: 350 bar
– Pilot Inlet / Drain Locations: Internal / external
– Seal Material: NBR
– Maximum Operating Temperature: 60 °C
– Minimum Operating Temperature: -20 °C
– Signal Input: 0 – ±10 V
– Fluid Compatibility: Hydraulic oil according to DIN 51524 … 535, Water glycol
– Weight: 9.3 kg
– Product Series: Proportional DC valve
– Mounting Type: Subplate mounting
– Seal Material: NBR
– Body Material: Cast iron
– Valve Option: Standard
– Connection Type: 6 + PE
– Spool Code: E01
Product Introduction:
The Parker D31FBE01EC1NF00 proportional valve belongs to Parker’s renowned standard performance pilot operated proportional DC valve series D31FB with onboard electronics. It is a versatile valve with progressive flow characteristics that allow for precise flow rate adjustment.
This valve utilizes advanced proportional solenoid technology for accurate and responsive control. It is a 3-way valve that can be operated in either position a or b for spool positioning. With a maximum operating pressure of 350 bar, it ensures reliable performance even in high-pressure applications.
The D31FBE01EC1NF00 proportional valve features internal and external pilot inlet/drain locations for efficient fluid flow control. The seal material used is NBR, which provides reliable sealing performance.
This valve is compatible with hydraulic oil according to DIN 51524…535 standards and water glycol fluids. The signal input range is 0 – ±10 V, and the flow direction is adjusted based on the signal input. Whether used in industrial machinery or other hydraulic systems, this valve offers precise flow control.
Made of cast iron, the D31FBE01EC1NF00 proportional valve is durable and robust. Its subplate mounting design allows for easy installation and maintenance.
In summary, the Parker D31FBE01EC1NF00 proportional valve is a high-performance pilot operated proportional DC valve with onboard electronics and progressive flow characteristics. Its reliability, precision, and durability make it an ideal choice for various hydraulic applications. Whether used in industrial machinery or other systems, the D31FBE01EC1NF00 proportional valve delivers excellent performance and precise flow control.
