Parker D1FBE02HC0NF00 Proportional Directional Control Valve

Description

Parker D1FBE02HC0NF00 Proportional Directional Control Valve

The D1FBE02HC0NF00 is a proportional directional control valve from Parker’s D*1FB series, designed for precise flow control in hydraulic systems.

The ordering code for the D1FBE02HC0NF00 valve is as follows:

Ordering Code: D1FBE02HC0NF00
D1FBE – Valve Series and Size
02 – Valve Function and Flow
HC – Valve Options and Connections
0N – Solenoid Voltage and Seal Material
F00 – Valve Design and Special Options

The D1FBE02HC0NF00 valve has the following key technical parameters:

– Valve Type: Proportional Directional Control Valve
– Actuation: Proportional Solenoid
– Size: NG10 (CETOP 05)
– Mounting Interface: DIN 24340 / ISO 4401 / CETOP RP121 / NFPA
– Operating Pressure Range: Up to 350 bar
– Operating Medium: Hydraulic oil according to DIN 51524 … 535, other on request
– Temperature Range: -20°C to +60°C
– Nominal Flow: Please refer to the specific flow characteristics in the catalog
– Leakage Rate: Please refer to the specific leakage rate in the catalog
– Solenoid Voltage: 0V as per the ordering code
– Seal Material: NBR
– Electrical Characteristics: Please refer to the specific electrical characteristics in the catalog
– Dimensions: Standard dimensions, please refer to the specific dimensions in the catalog

The D1FBE02HC0NF00 valve is suitable for various hydraulic applications that require precise flow control. It features progressive flow characteristics and meets Parker’s high-quality standards.

For more information about the D1FBE02HC0NF00 valve and other proportional valves from Parker, please visit their official website or refer to the relevant catalog.
