Parker CS400S pressure relief valve
Parker’s CS400S is a compact and efficient pressure relief valve designed for use with hydraulic systems. This valve is known for its high performance, reliability, and superior durability. With a maximum flow rate of 20 gallons per minute (75 liters per minute) and maximum pressure of 5500 PSI (380 Bar), the CS400S is well-suited for use in demanding applications.
Description
Parker CS400S pressure relief valve
Brand: Parker Model: CS400S
Product Description:
Parker’s CS400S is a compact and efficient pressure relief valve designed for use with hydraulic systems. This valve is known for its high performance, reliability, and superior durability. With a maximum flow rate of 20 gallons per minute (75 liters per minute) and maximum pressure of 5500 PSI (380 Bar), the CS400S is well-suited for use in demanding applications.
Technical Specifications:
Flow Rate: 20 gal/min (75 lpm)
Max Inlet Pressure: 5500 PSI (380 Bar)
Pressure Control Range: 500-5000 PSI (34.5-350 Bar)
Adjustment Mechanism: Screw
Standard Setting Pressure: 2500 PSI (172 Bar)
Seal Material: D-Ring (Standard)
Mounting Type: Screw-in Cartridge Valve
Cracking Pressure: N/A
Division: Hydraulic Cartridge Systems Division
Maximum Flow Rate: 20 gal/min (75 lpm)
Maximum Operating Pressure: 5500 PSI (380 Bar)
Minimum Operating Pressure: N/A
Maximum Tank Pressure: 5000 PSI (350 Bar)
Maximum Pressure Setting: 5000 PSI (350 Bar)
Pressure Control Sensitivity: 589 per turn PSI (40.6 per turn Bar)
Reseat Pressure: 85% of pressure setting
Actuation Type: Pressure Sensing
Configuration: Differential Area Relief, Differential Relief w/Reverse Flow Check
Leak Rate: 5 @ 75% Crack Pressure drops/min, .33 @ 75% Crack Pressure cm3/min
Cavity Size: C10-2
Function: Direct Acting
Operation Type: Automatic
For Fluid Type: Mineral-based or synthetic hydraulic fluids
Maximum Kinematic Viscosity: 45-2000 SSU (6 to 420 cSt)
Filter Efficiency Rating: ISO 4406 18/16/13, SAE Class 4
Valve Material: All parts steel. All operating parts hardened steel
Body Material: N/A
Port Thread Size: N/A
Installation Torque: 51-55 lb-ft, 69-75 Nm
Operating Temperature: -35 to +200 °F (-37 to +93 °C)
Maximum Operating Temperature: +200 °F (+93 °C)
Minimum Operating Temperature: -35 °F (-37 °C)
Weight: 0.5 lb (0.23 kg)
Features:
– Compact and efficient design
– High performance and reliability
– Superior durability
– Screw-in cartridge valve for ease of installation
Applications:
– Hydraulic systems requiring pressure relief valves
– Heavy equipment and machinery
– Mining and construction equipment
– Oil and gas industry equipment
Conclusion:
Parker’s CS400S pressure relief valve is a high-quality solution for hydraulic systems requiring pressure relief. With its compact and efficient design, this valve provides reliable performance and superior durability. Its screw-in cartridge valve makes it easy to install, making it a great choice for heavy equipment and machinery, mining and construction equipment, and oil and gas industry applications.
