Parker CPOM6AAV Pilot Operated Check Valve

Description

Parker CPOM6AAV Pilot Operated Check Valve

The Parker CPOM6AAV pilot-operated check valve is a high-performance hydraulic valve designed for reliable operation in a variety of applications. This check valve is part of Parker’s standard options and is mounted using a sandwich plate configuration. It operates with a cracking pressure of 1 bar and has an opening pressure ratio of 1:3. The valve body is made of steel, providing durability and strength.

The CPOM6AAV check valve offers a maximum flow rate of 227 L/min, making it suitable for high-flow hydraulic systems. It has a wide operating temperature range, with a minimum operating temperature of -20 °C and a maximum operating temperature of 60 °C. The valve is designed for hydraulically actuated operation, providing precise control and responsiveness.

With a maximum operating pressure of 210 bar, this check valve can handle demanding hydraulic applications. It has a weight of 9.5 kg, which ensures stability and durability during operation. The port connection size is NG25 (CETOP 08), offering compatibility with standard hydraulic systems.

The CPOM6AAV check valve features a poppet-style design (Style A) and utilizes FPM seal material, known for its resistance to high-pressure and temperature conditions. The valve is suitable for various hydraulic systems where reliable flow direction control is essential.

In summary, the Parker CPOM6AAV pilot-operated check valve is a robust and versatile hydraulic valve designed to provide optimal performance in demanding industrial applications. Its steel body construction, high flow rate, and wide operating temperature range make it suitable for a range of hydraulic systems. Whether in high-pressure or high-temperature environments, this check valve delivers reliable and efficient flow direction control.
