Parker CCP024D 1/2" Super Coil

Description

Parker CCP024D 1/2″ Super Coil

The Parker 1/2″ Super Coil is a robust and durable coil designed for challenging environments. It has the following technical specifications:

– Power Consumption: 19 – High Watt
– Voltage: 24 VDC
– Diode: No
– Resistance: 30.3 Ω
– Function: 1/2″ Super Coil
– Maximum Operating Temperature: +392 °F, +200 °C
– Weight: 0.44 lb, 0.2 kg
– Body Material: N/A
– For Fluid Type: N/A
– Maximum Operating Pressure: N/A
– Division: Hydraulic Cartridge Systems Division
– Connection Type: Din
– Current: 0.79 A
– Duty Cycle: Continuous @ 100% voltage
– Coil Type: Puissant
– Minimum Operating Temperature: -40 °F, -40 °C
– Actuation Type: N/A
– Flow Rate: N/A
– Maximum Flow Rate: N/A
– Seal Material: N/A

The 1/2″ Super Coil is designed to have a longer life at typical temperatures, with internal wires rated at class N. It is available in various terminations to meet system requirements, including integrally molded connectors. The coil is encased in a thermoplastic polyester resin, which allows for higher temperature exposure and provides protection against moisture, caustic solutions, and fungus. The coil has a zinc-plated low carbon steel frame, which increases flux density and provides better magnetic properties. The coil has undergone extensive testing, including water dunk, endurance, and high-pressure water tests, making it suitable for demanding applications.

Please note that specific information regarding the body material, fluid type, and maximum operating pressure is not provided in the specifications. For more detailed information or specific application requirements, it is recommended to consult the product manual or contact Parker directly.
