Parker BGT1720QBPER323 Filter

Description

Parker BGT1720QBPER323 Filter
Product Description for Parker BGT1720QBPER323 Filter

Model: BGT1720QBPER323

Key Specifications:

– Parker BGT series tank-mounted return line filter
– Flow rate: 2000 L/min
– Maximum working pressure: 10 bar
– Tank-mounted design

Main Features:

– Element length code 17, suitable for BGT2000 housing
– 20 micron absolute filtration rating (20Q) disposable filter element
– NBR seals (B)
– Bypass valve setting at 1.5 bar (E)
– Without indicator (P)
– Includes magnet and type T diffuser (R48)
– 3″ SAE port (48)

Technical Parameters:

– Achieves 99.5% efficiency per ISO16889 β200 rating
– Element burst pressure 10 bar
– Element material: Filter media encapsulated in stainless steel end caps
– Seal operating temperature: -40°C to +100°C
– Housing material: Die-cast aluminum

Benefits:

– Compact design, small footprint
– Can filter down to 20 microns
– Low cost disposable element suitable for general applications
– Low hysteresis bypass valve ensures effective filtration
– Suitable for general industrial and mobile hydraulic systems

In summary, the BGT1720QBPER323 is a 2000 L/min tank-mounted return line filter. It uses a cost-effective 20 micron disposable filter element suitable for routine filtration applications in general industrial and mobile hydraulic systems.
