Parker BGT1110QBPER323 Filter

Description

Parker BGT1110QBPER323 Filter

Product Description of Parker BGT1110QBPER323 Filter

Model: BGT1110QBPER323

Specifications:

– Filter Type: BGT390
– Element Length: Length Code 11
– Flow Rate: 500 L/min
– Ports: 2″ SAE threaded ports
– Micron Rating: 10 microns

Key Features:

– Utilizes a single-use 10 micron filter element
– Magnetic pre-filtration to remove ferrous particles
– In-to-out head design prevents backflow contamination
– Low hysteresis bypass valve
– Maximum working pressure of 10 bar

Performance:

– Provides 90% efficiency at 10 microns as per ISO 16889
– Element burst pressure of 10 bar
– Suitable for mineral and HEES oils

Benefits:

– Delivers 10 micron level cleanliness
– Magnetic pre-filtration improves fluid cleanliness
– Single-use element simplifies maintenance
– Low hysteresis bypass extends element life
– In-to-out head design prevents system recontamination

In summary, the BGT1110QBPER323 is a Parker BGT390 model single-use 10 micron filter suitable for flows up to 500 L/min. It features magnetic pre-filtration, low hysteresis bypass and in-to-out head design for reliable performance and simple maintenance.
