Parker 9F2400S Flow Control Valve

Description

Parker 9F2400S Flow Control Valve

Parker 9F2400S Flow Control Valve Product Introduction

Product Type:
The Parker 9F2400S is a F series one-way flow control valve.

Specifications:
1. Valve Body Size: 1/2 inch (Size Code 400)
2. Valve Body Material: Steel (Material Code S)
3. End Connection: BSPP thread (Connection Code 9)
4. Flow Direction Control: Can precisely control flow in one direction and fully open in the other direction automatically (Function Code F)

Main Features:
1. Precisely controls flow rate or shuts off flow in one direction, and automatically fully opens flow in the other direction.
2. Larger 1/2 inch size suitable for medium flow applications compared to smaller sizes.
3. Uses steel body with high strength and pressure resistance up to 350 bar.
4. BSPP threaded connection for easy installation.
5. Features Parker’s exclusive “Colorflow” visible indicator for quick valve setting.

Application:
The 9F2400S is suitable for applications requiring uni-directional flow control of medium flows in hydraulic or pneumatic systems, such as flow control manifolds.

Installation and Operation:
1. Ensure correct installation of flow direction.
2. Adjust flow by turning the knob and check flow using the “Colorflow” indicator.
3. Lock setting with set screw.
4. Check for leaks during use and repair or replace in case of malfunction.

In summary, the Parker 9F2400S one-way flow control valve is designed for medium flow applications with reliable flow control and shut-off in one direction through a 1/2 inch steel body. Please select the appropriate model according to the required specifications.
