Parker 9C800B Check Valve

Description

Parker 9C800B Check Valve

Product Name: Parker 9C800B C Series Check Valve

Product Description:
The Parker 9C800B C Series Check Valve is an economical and versatile check valve designed to allow gas, water, and oil to flow freely in one direction while reliably stopping flow in the reverse direction. This valve is suitable for hydraulic, water, and air media and offers various connection types and material options to meet different requirements.

Technical Specifications:
– Configuration: In-line
– Function: Check
– Connection Type: BSPP
– Media: Hydraulic Oil, Water, Air
– Flow Direction: Free Flow in one Direction, shut-off in reverse
– Maximum Operating Temperature: 250°F (121°C)
– Minimum Operating Temperature: -40°F (-40°C)
– Installation Type: In-line
– Actuation Type: Mechanical
– Maximum Operating Pressure: 2000 psi
– Flow Rate: 15 g/min
– Connection Size: 1/2″
– Valve Body Material: Brass
– Seal Material: Nitrile

Features and Options:
– Threaded Port Options: ISO 6149, NPT, BSPP, BSPT, SAE
– Valve Body Material Options: Brass, Carbon Steel, Stainless Steel
– Standard Type: Carbon Steel with surface oxidation treatment

The Parker 9C800B C Series Check Valve is a Colorflow product known for its reliable performance and wide applicability across various industrial applications.
