Parker 936-071161-010 VSO LowPro GC Miniature Proportional Valve

Description

Parker 936-071161-010 VSO LowPro GC Miniature Proportional Valve

Parker 936-071161-010 VSO® LowPro GC Miniature Proportional Valve

Product Overview
The Parker 936-071161-010 VSO® LowPro GC is an ultra-compact proportional valve designed for space-constrained applications. Employing advanced electromagnetic driving technology, this valve measures only 16 mm in diameter and 14 mm in height, making it highly suitable for integration into portable devices or equipment with tight internal space requirements.

The VSO® LowPro GC Miniature Proportional Valve is widely used in gas chromatography analyzers, PEEP flow control in respiratory ventilators, and other portable or space-limited devices that require precise gas flow control.

Key Technical Specifications

Performance Characteristics:
– Operating Pressure Range: 0 to 150 psi (0 to 10.3 bar)
– Orifice Size: 0.007 inches (0.18 mm)
– Maximum Flow: 3.5 SLPM
– Vacuum to Pressure Range: 27 inHg to 150 psi
– Maximum Operating Pressure: 150 psi, 10.3 bar

Materials:
– Valve Body: C36000 Brass
– Seals: FFKM
– Spring: 17-7 Stainless Steel
– Armature: Nickel-plated 1018 Carbon Steel

Electrical Specifications:
– Operating Voltage: 16 VDC
– Power Consumption: 0.7 W
– Response Time: 10 ms (typical)
– Electrical Connection: 4.5-inch Leads

Environmental Conditions:
– Operating Temperature Range: -20°C to 85°C
– Mounting: Flange, Screw

Other Specifications:
– Leakage Rate: Less than 0.030 SCCM Helium at 150 psi
– Cycle Life: 100 million cycles
– Weight: 0.56 oz, 19 g
– Dimensions: Length 0.80 inches (20 mm), Width 0.63 inches (16 mm), Height 0.53 inches (14 mm)

Key Features:

1. Ultra-compact size for space-constrained applications
2. Fast response time for rapid switching control
3. Maximum flow rate of 3.5 SLPM with precise flow control
4. Low power consumption of only 0.7 W
5. Exceptionally low leakage rate, less than 0.030 SCCM Helium
6. Wide operating temperature range for harsh environments
7. Excellent corrosion resistance for diverse media

The outstanding performance characteristics and ultra-compact design of the VSO® LowPro GC Miniature Proportional Valve make it an ideal choice for gas chromatography analyzers, respiratory ventilators, and other portable or space-limited applications.
